27717-X | Dana Loaded Differential Case | Dana 70-B | 1.500"-23 Spline A-Gears | New OE

27717-X Dana Spicer Loaded Differential Case — Dana 70-B | 1.500"–23 Spline A-Gears | 2-Pin Case | 4.56 & Up | New OE

Product Summary

Genuine Dana Spicer loaded differential case for Dana 70-B axles (standard case, not Power Lok). New OE assembly set up for 1.500"–23 spline axle (A-gears), compatible with 4.56 and higher ring gear ratios. Features a 2-pin case design and a 1/2" offset.

Specs & Features

For Use With

• Dana 70-B axle assemblies (standard case, not Power Lok)

Included in This Sale

• Dana Spicer 27717-X Loaded Differential Case
• Includes internal parts matching Dana Spicer 706056X (unloaded case assembly reference)

Reference Only (Not Included Unless Noted)

• Dana Spicer 35077 Differential Carrier
• Dana Spicer 40638 Ring Gear Bolts (Not Included)
• Dana Spicer 47024 Roll Pin
• Dana Spicer 70812 Diff Carrier Bearing Shim (Not Included)
• Dana Spicer 706202X Inner Parts Kit (reference)
• Dana Spicer 36353 Axle Gears (1.500" – 23 Spline)
• Dana Spicer 35080 Pinion Gears
• Dana Spicer 35082 Thrust Washers, Pinions
• Dana Spicer 34729 Thrust Washers, Axle Gears
• Dana Spicer 46640 Pin, Differential Pinion
• Dana Spicer 47024 Roll Pin
• Dana Spicer 34687 Diff Cover Gasket (Not Included)
• Alternate kit number 706198X (includes shim kit 708012 and bearings 706047X — Not Included)

Notes

• Not Power Lok (standard Dana 70-B case)
• Verify ratio (4.56 & up) and spline spec (1.500"–23) for your application

Location

Ships from our warehouse in Mansfield, Ohio.
